Automatic Slack Adjuster
Twin-Cyl.Compressor 704cc,flangemounted
Material Number:
4332251740
Bruto cena na enoto:
0.00
Features and Benefits
-
BrandWABCO
-
Part typePremium original quality
-
Actuating directionCounterclockwise
-
Calculated Volume (dm³)2.067
-
Clevis pins14.2 + 5x 14.2 mm
-
Length4.72 / 5.31 / 5.91 / 6.50 / 7.09 / 9.84 in
-
Length of lever120 / 135 / 150 / 165 / 180 / 250 mm
-
Number of Connectors6
-
Product CategoryDevice
-
Technical SpecificationOE specification
-
VerzijaAutomatic
-
Wrench sizeHEX12
-
vgradnja dodatkaInternal Spline : Spline standard:ANSI B92.1, tolerence class 6 x 37 Teeth x45° x 24/48
-
GTIN04057875442110
-
Size (mm x mm x mm)330 x 116 x 54
-
UPC193133402787
-
Weight (kg)3.2
-
Weight (lb)7.055
Doc Type
drawing
Locale
en
Artical Number
4332251740____005_dascheck_-4_page-1---notset
Servis in popravilo
Seznam nadomestnih delov
| 1 | Karoserija | 1 | ||
| 2 | Gear | 1 | ||
| 3 | O-Ring, dynamical ISO3601-12.37x2.62 | 1 | ||
| 4 | Gear | 1 | ||
| 5 | Bearing | 1 | ||
| 6 | O-Ring, dynamical | 1 | ||
| 7 | Cover | 1 | ||
| 8 | Rivet Pin | 2 | ||
| 9 | Spring Seat | 1 | ||
| 10 | Compression Spring, special | 1 | ||
| 11 | O-Ring, dynamical | 1 | ||
| 12 | Spring guide | 1 | ||
| 13 | Slotted pan head screw; A | 1 | ||
| 14 | Guide | 1 | ||
| 15 | Gear | 1 | ||
| 16 | Torsion spring | 1 | ||
| 17 | Gear | 1 | ||
| 18 | Spring | 1 | ||
| 19 | O-Ring, statical | 1 | ||
| 20 | Gear/Pinion | 1 | ||
| 21 | O-Ring, statical | 1 | ||
| 22 | Gasket, flat | 1 | ||
| 23 | Arm | 1 | ||
| 24 | Countersunk Screw, full thread | 7 | ||
| 25 | Bush | 5 |
