Twin-Cyl.Compressor 704cc,flangemounted
Material Number:
9650010550
Gross Unit Price: 0.00
Create an account
You must be logged-in to make a purchase.
Don't have an account yet?
Please register.

Features and Benefits

  • Brand
    WABCO
  • Part type
    Premium original quality
  • Application
    DAF
  • Calculated Volume (dm³)
    65.36
  • Electrical connection
    TYCO C-114-18740-1 Rev "D"
  • Max. operating pressure
    12.5 bar
  • Port thread 11
    Voss 232 NG8
  • Port thread 12
    Voss 232 NG8
  • Port thread 2
    M14 x 1.5
  • Port thread 21
    Voss 230 NG8
  • Port thread 22
    Voss 232 NG8
  • Port thread 3
    Integrated silencer
  • Product category
    Device
  • Stroke
    85/135 mm
  • Technical specification
    OE specification
  • Temperature range
    -35°C to +70°C
  • Type
    Brake Pedal and Clutch Pedal
  • Voltage
    24 V
  • GTIN
    04057875299158
  • Size (mm x mm x mm)
    430 x 380 x 400
  • UPC
    193133416166
  • Weight (kg)
    7.169
  • Weight (lb)
    15.8
Replaces
  • DAF
    1845530
  • DAF
    1974276
Documents
Name
outline drawing (doc 005)
Doc Type
drawing
Locale
multi
Artical Number
9650010550____005_dascheck_e8_page-1---notset
Name
WABCO Product Catalogue
Doc Type
catalog
Locale
en
Artical Number
wabco_product-catalogue

Service & Repair

List of Spare Parts
1 Housing 1
2 Brake signal transmitter - 3 1 4800030340
3 Shaft 1
4 Hexagon socket set screw 1
5 Spring Element 1
6 Bearing Bush 1
7 Retaining ring DIN471-A6x0,7 1
8 Pedal 1
9 Treadle Cover 1
10 PIN 1
11 Plain bearing 2
12 Bush 1
13 Lever 1
14 Cheese Head Screw 1
15 Knob 1
16 Push Rod 1
17 Hexagon Nut with Washer M8 4
