Twin-Cyl.Compressor 704cc,flangemounted
Material Number:
9650012880
Gross Unit Price:
0.00
Features and Benefits
-
BrandWABCO
-
Part typePremium original quality
-
Calculated Volume (dm³)40.93
-
Max. operating pressure11.0 bar
-
Port thread 3Oil Inlet
-
Product categoryDevice
-
Stroke97.00 mm
-
Technical specificationOE specification
-
Temperature range-40°C to +80°C
-
TypePedal Unit
-
GTIN04057876243716
-
Size (mm x mm x mm)359 x 309 x 369
-
UPC193133534532
-
Weight (kg)6
-
Weight (lb)13.23
Doc Type
drawing
Locale
en
Artical Number
9650012950____053_dascheck_e13_page-1---notset
Service & Repair
List of Spare Parts
| 1 | Body Pneumatic | 1 | ||
| 2 | Piston | 1 | 100630122 | |
| 3 | O-Ring, dynamical | 2 | 300006051 | |
| 4 | O-Ring, statical | 1 | 300006051 | |
| 5 | Wire clip | 1 | ||
| 6 | Filter | 2 | 300006051 | |
| 7 | O-Ring, statical | 2 | 300006051 | |
| 8 | O-Ring, dynamical ISO3601-25.07x2.62 | 2 | 300006051 | |
| 9 | Spring | 2 | 300006051 | 100632780 |
| 10 | O-Ring, dynamical ISO3601-15.55X2.62 | 2 | 300006051 | |
| 11 | Valve | 2 | 300006051 | |
| 12 | Body --upper | 1 | ||
| 13 | Spring | 1 | 100630230 | |
| 14 | Piston | 1 | 100630162 | |
| 15 | Guide ring | 2 | 300006051 | |
| 16 | O-Ring, dynamical | 1 | 300006051 | |
| 17 | Rubber spring | 1 | 300006051 | |
| 18 | Spring washer | 1 | 300006051 | |
| 19 | Retaining ring DIN472-45x1,75 | 1 | ||
| 20 | Protection Hood | 1 | 300006051 | |
| 21 | Spacer | 1 | 100630240 | |
| 22 | Retaining Ring | 1 | 8952212104 | |
| 23 | Plunger | 1 | 100630190 | |
| 24 | Pushrod | 1 | ||
| 25 | Socket | 1 | ||
| 26 | Hexagon Head Screw, full thread | 4 | ||
| 27 | O-Ring, dynamical | 1 | 300006051 | |
| 28 | Exhauster | 1 | 100632760 | |
| 29 | Wire clip | 1 | ||
| 30 | Filter | 1 | 300006042 | |
| 31 | Cover | 1 | 300006042 | |
| 32 | Hexagon Head Screw ISO4017-M8x25 | 2 | 8101260624 | |
| 33 | Hexagon Nut DIN934-M8 | 2 | 8103041114 | |
| 34 | Hexagon Nut with Washer M8 | 2 | ||
| 35 | Spider Plate | 1 | ||
| 36 | Gasket | 1 | ||
| 37 | Hexagon head screw ISO4014-M8x60 | 1 | ||
| 38 | 1 | |||
| 39 | Support | 1 | 9700013534 | |
| 40 | Fillister head screw ISO14583-M5x25 | 2 | ||
| 41 | Switch | 1 | 9650015302 | |
| 42 | Support | 1 | ||
| 43 | Damper | 1 | ||
| 44 | Hexagon Flange Bolt | 2 | ||
| 45 | Pedal Brake | 1 | ||
| 46 | Pedal Clutch | 1 | ||
| 47 | Housing | 2 | ||
| 48 | Cylindrical compression spring | 2 | ||
| 49 | Cam | 2 | ||
| 50 | Cheese Head Screw | 2 | ||
| 51 | Extension Spring | 2 | 8965172514 | |
| 52 | Pedal Cover | 2 | ||
| 53 | Shaft | 1 | 9650017722 | |
| 54 | Clamp | 1 | ||
| 55 | Gasket | 1 | ||
| 56 | O-Ring, dynamical | 2 | ||
| 57 | Washer, special type | 2 | 8951800034 | |
| 58 | Screw plug | 2 | 8932800214 |
