Exhaust Brake assembly
Vehicle application (India): Volvo Eicher (VECV)
Twin-Cyl.Compressor 704cc,flangemounted
Material Number:
4214292690
Brutto pris:
0.00
Vehicle application (India): Volvo Eicher (VECV)
Funktioner och Fördelar
-
MärkeWABCO
-
Teknisk SpecifikationOE Specifikation
-
ProduktkategoriEnhet
-
Beräknad volym (dm³)8.563
-
Typ av artikelPremium Original Kvalitet
-
GTIN04057875904519
-
Size (mm x mm x mm)287.5 x 136 x 219
-
UPC193133499343
-
Vikt (kg)5.2
-
Vikt (lb)11.46
Doc Type
drawing
Locale
en
Artical Number
4214292690____005_dascheck_c6_page-1---notset
Service & Reparation
Lista över reservdelar
| 1 | Housing machined | 1 | ||
| 2 | Bussning | 1 | 4214299492 | |
| 3 | Stift | 1 | 4214299492 | |
| 4 | Skylt Baffle | 1 | ||
| 5 | Bussning | 1 | 4214299492 | |
| 6 | Haevstang shaft | 1 | 4214299492 | |
| 7 | Hexagon Head Screw, special | 2 | 4214299492 | |
| 8 | Bracket assembly | 1 | ||
| 9 | Hexagon Screw With Flange | 2 | 4214299492 | |
| 10 | Arm / Spak | 1 | 4214299492 | |
| 11 | Skruv | 1 | 4214299492 | |
| 12 | Hexagon Flange Nut M6 | 1 | 4214299492 | |
| 13 | Ball Joint DIN71802-/ | 1 | 4214299492 | |
| 14 | Cylinder machined | 1 | ||
| 15 | O-Ring, statical | 1 | 4214299492 | |
| 16 | Washer, special type | 1 | 8951800004 | |
| 17 | Voss adapter erfordras | 1 | 100932810 | |
| 18 | Spring Retainer | 1 | 4214299492 | |
| 19 | Fästring | 1 | 4214299492 | 8952267064 |
| 20 | Male Nut | 1 | 4214299492 | 8932204282 |
| 21 | O-Ring, statical | 1 | 4214299492 | |
| 22 | O-Ring, statical | 1 | ||
| 23 | Kanttätning | 1 | 4214299492 | |
| 24 | Kolv | 1 | ||
| 25 | Locking nut | 2 | 4214299492 | |
| 26 | Kolv Rod | 1 | 4214299492 | |
| 27 | Compression Spring, special | 1 | 4214299492 | |
| 28 | Fjäder | 1 | 4214299492 | |
| 29 | Packning / Tätning | 1 | 4214299492 | |
| 30 | Filter | 1 | 4214299492 | |
| 31 | Sil | 1 | 4214299492 | |
| 32 | Fjäderring | 1 | 4214299492 | |
| 33 | Lock Protection | 1 | 4214299492 | |
| 34 | Wiper Ring | 1 | 4214299492 | |
| 35 | BALL SOCKET DIN71804-/ | 1 | 4214299492 | |
| 36 | Bush-Air Cylinder | 1 | 4214299492 | |
| 37 | Washer 8,4x17x2 | 1 | 4214299492 | |
| 38 | Nut, special type | 1 | 4214299492 |
