Load sensing valve
Vehicle application (India): TATA
Twin-Cyl.Compressor 704cc,flangemounted
Material Number:
4758000380
MRP:
3413.00
Vehicle application (India): TATA
Features and Benefits
-
BrandWABCO
-
Part typePremium original quality
-
Calculated Volume (dm³)8.736
-
Product categoryDevice
-
Technical specificationOE specification
-
GTIN04057875656227
-
Size (mm x mm x mm)260 x 160 x 210
-
Weight (kg)2.3
-
Weight (lb)5.071
Doc Type
drawing
Locale
en
Artical Number
4758000380____005_dascheck_a6_page-1---notset
Service & Repair
List of Spare Parts
| 1 | ALSV Lower Body PDC Machined | 1 | ||
| 2 | Seal | 1 | ||
| 3 | TAPPET & ROLLER ASSY | 1 | ||
| 4 | Circlip | 1 | ||
| 5 | Retaining plate | 1 | ||
| 6 | Diaphragm | 1 | ||
| 7 | Diaphragm part | 1 | ||
| 8 | Valve | 1 | ||
| 9 | Flexible bottom | 1 | ||
| 10 | Spring | 1 | ||
| 11 | Spring guide | 1 | ||
| 12 | Circlip | 1 | ||
| 13 | Dip | 1 | ||
| 14 | O-Ring, dynamical | 1 | ||
| 15 | Spring guide | 1 | ||
| 16 | Spring box | 1 | ||
| 17 | Valve | 1 | ||
| 18 | Circlip | 1 | ||
| 19 | Valve Unit | 1 | ||
| 20 | O-Ring, dynamical | 1 | ||
| 21 | Valve | 1 | ||
| 22 | O-Ring, dynamical ISO3601-15.55X2.62 | 1 | ||
| 23 | Spring | 1 | ||
| 24 | ALSV Upper Body PDC machined | 1 | ||
| 25 | Hexagon Head Screw | 3 | ||
| 26 | Hexagon Head Screw, full thread | 1 | ||
| 27 | Bush | 1 | ||
| 28 | Camshaft | 1 | ||
| 29 | Grooved Pin | 1 | ||
| 30 | Sealing | 1 | ||
| 31 | Clamping Unit | 1 | ||
| 32 | Pan Head Screw | 1 | ||
| 33 | Hexagon Nut | 1 | ||
| 34 | Hose Clamp | 1 | ||
| 35 | Lever | 1 | ||
| 36 | Cap | 1 | ||
| 37 | Elongation | 1 | 100925300 | |
| 37 | Kit: Linkage | 1 | 4758009202 | |
| 38 | Kit: Linkage | 1 | 4758009202 | |
| 38 | Clamping Unit | 1 | ||
| 39 | Kit: Linkage | 1 | 4758009202 | |
| 39 | Washer | 2 | ||
| 40 | Kit: Linkage | 1 | 4758009202 | |
| 40 | Split pin ISO1234-1.75x12 | 2 | ||
| 41 | Angle | 1 | ||
| 42 | Hexagon Head Screw | 1 | ||
| 43 | Torsion spring | 1 | ||
| 44 | Came | 1 | ||
| 45 | O-Ring, dynamical | 1 | ||
| 46 | Support | 1 | ||
| 47 | Silencer | 1 | ||
| 48 | Countersunk head screw | 4 | ||
| 49 | Pressure Switch | 2 | 100304202 | |
| 50 | O-Ring, dynamical | 2 | ||
| 51 | Washer, special type | 2 | 8951800034 | |
| 52 | Adapter, inside/outside thread | 2 | ||
| 53 | Spring Retainer | 1 | 4611001192 | |
| 54 | Retaining Ring | 1 | 4611001192 | 8952266974 |
| 55 | Pressure screw | 1 | 4611001192 | 8932204272 |
| 56 | O-Ring, statical | 1 | 4611001192 | |
| 57 | O-Ring, statical | 1 | 4611001192 |
