Twin-Cyl.Compressor 704cc,flangemounted
Part Number::
4230700500
Gross Unit Price: 0.00
Create an account
You must be logged-in to make a purchase.
Don't have an account yet?
Please register.

Features and Benefits

  • Brand
    WABCO
  • Part type
    Premium original quality
  • Product category
    Device
  • Bolt lengths
    0.98 in
  • Calculated Volume (dm³)
    0
  • Clamp band
    145 mm
  • Max. operating pressure
    116.0 psi
  • Mounting
    M48 x 1.5
  • Operating pressure
    116.0 psi
  • Output force
    1169.01 lbf
  • Output force M
    1169.01 lbf
  • Port (top)
    M16 x 1.5
  • Port threads
    M16 x 1.5
  • Return-spring force
    33.72 lbf
  • Stroke
    2.09 in
  • Technical specification
    OE specification
  • Temperature range
    -40°C to +80°C
  • Thread length
    1.59 in
  • Total lenght
    6.85 in
  • Type
    12
  • Type of operation
    Wedge
  • Version
    Without boot
  • GTIN
    04057875161851
  • Weight (kg)
    2.4
Replaces
  • DAF
    1517949
  • IVECO
    98474559
  • MAN
    81511016278
  • MAN
    81511016281
  • MAN
    81511016283
  • MAN
    81511016286
  • MAN
    81511019283
  • NEOPLAN
    81511016283
Documents
Name
WABCO Product Catalogue
Doc Type
catalog
Locale
en
Artical Number
wabco_product-catalogue

Service & Repair

List of Spare Parts
1 Cylinder 1
2 Hose Clamp 1
3 Cheese head screw DIN6912-M8x35 1
4 Hexagon Nut 1 8915002904
5 Diaphragm 180 1 4230700012  8971205054
6 Piston 1
7 Tolerance ring 1 4230700012
8 Washer 1 8951112794
9 Retaining ring DIN471-A16x1 1 4230700012
10 Pressure Plate 1
11 Bronze Bushing 1 4230700012
12 O-Ring ISO3601-29,2x3 1 4230700012  8970800604
13 Cylinder cover 1
