Brake Chamber (Disc brake)

Brake Chamber (Disc brake)
Brake Chamber (Disc brake)
Twin-Cyl.Compressor 704cc,flangemounted
Part Number::
4235050600
Gross Unit Price: 0.00
Create an account
You must be logged-in to make a purchase.
Don't have an account yet?
Please register.

Features and Benefits

  • Brand
    WABCO
  • Part type
    Premium original quality
  • Product category
    Device
  • Bolt lengths
    1.50 in
  • Bolt threads
    M16 x 1.5
  • Calculated Volume (dm³)
    4.5783
  • Distance between bolts
    4.75 in
  • Max. operating pressure
    145.0 psi
  • Port threads
    M16 x 1.5
  • Push-rod length
    0.59 in
  • Push-rod thread
    Ball R8
  • Return-spring force
    33.72 lbf
  • Stroke
    2.24 in
  • Technical specification
    OE specification
  • Temperature range
    -40°C to +80°C
  • Total lenght
    4.06 in
  • Type
    20
  • Type of operation
    Disc
  • Version
    Without boot
  • GTIN
    04057875165835
  • Size (mm x mm x mm)
    170 x 141 x 191
  • UPC
    193133249603
  • Weight (kg)
    3.093
  • Weight (lb)
    6.8189
Documents
Name
outline drawing -table (doc 053)
Doc Type
drawing
Locale
multi
Artical Number
4235050690_-_653_-_01
Name
NEW UNISTOP™ BRAKE CHAMBER FOR AIR DISC BRAKES
Doc Type
market_information
Locale
en
Artical Number
14200

Service & Repair

List of Spare Parts
1 Cylinder 1 4231050102
2 Hose Clamp 1 4231053504
3 Diaphragm 115 1 4231050042  8971205204
4 Piston 1
5 Cover 1 8950726204
6 Compression spring 1 8960801704
7 Boot 1 4231050042  8977548862
8 Cylinder cover 1 4231056612
9 Ring 1 4231050042
10 Washer 1 8951112794
11 Pressure piece 1
12 Hexagon Nut DIN934-M8 1 8103041114
13 Hexagon Head Screw ISO4017-M8x50 1 8101263284
14 Plug 4 4231050042  4230060404
