ECAS Solenoid Valve
Vehicle application (India): TATA
Twin-Cyl.Compressor 704cc,flangemounted
Part Number::
4728800640
Gross Unit Price:
0.00
Vehicle application (India): TATA
Features and Benefits
-
BrandWABCO
-
Part typePremium original quality
-
Product categoryDevice
-
Calculated Volume (dm³)3.8327
-
Electrical connectionBayonet DIN 72585-A1-4.1-Sn/K2, Bayonet DIN 72585-A1-3.6-Sn/K2
-
Max. operating pressure290.1 psi
-
Mounting2 x Ø 9 mm
-
Multi Nominal diameter (From Port 1 to x)0.39 / 0.28 / 0.02 in
-
Port thread 11M22 x 1.5 JED - 388
-
Port thread 21M22 x 1.5 JED - 388
-
Port thread 22M22 x 1.5 JED - 388
-
Port thread 23M22 x 1.5 JED - 388
-
Port thread 3Silencer 432 407 060 0
-
Protection classIP 6K9K
-
Rated current320 mA
-
Technical specificationOE specification
-
Temperature range-40°C to +80°C
-
Voltage24 V
-
GTIN7895851040755
-
Size (mm x mm x mm)205 x 164 x 114
-
UPC193133444015
-
Weight (kg)2.482
-
Weight (lb)5.4719
Replaces
-
ALEXANDER DENNIS662174
-
DAF1150130
-
DAF1525422
-
EVOBUSA0003279725
-
FOTON1618029600001
-
IRIZAR8015529
-
KENWORTHS472-880-064-0
-
MACK6300-4728800640
-
MAN2Z0601361F
-
MAN2Z0607361F
-
MERCEDES-BENZA0003279725
-
MERCEDES-BENZ0003279725
-
MERITORS4728800640
-
PETERBILTS472-880-064-0
-
SCANIA1453163
-
SHAANXI6180J3629112
-
VDL759000174
-
VDL41150130
-
VOLVOWAB4728800640
-
VW2Z0601361G
-
YUTONG350601316
Doc Type
drawing
Locale
multi
Artical Number
4728800640____005_dascheck_g4_page-1---notset
Doc Type
system_description
Locale
en
Artical Number
81500273
Service & Repair
List of Spare Parts
| 1 | Body | 1 | ||
| 2 | Spacer | 3 | ||
| 3 | Sealing ring | 3 | 4728809342 4728809372 | |
| 4 | Spacer | 2 | ||
| 5 | Spacer | 1 | ||
| 6 | Sealing ring | 3 | 4728809342 4728809372 | |
| 7 | Bushing | 2 | ||
| 8 | Bushing | 1 | ||
| 9 | Compression Spring | 3 | ||
| 10 | Lip seal ring | 3 | 4728809342 4728809372 | |
| 11 | Plunger | 3 | ||
| 12 | Sealing | 1 | 4728809202 4728809342 4728809372 | |
| 13 | Sheet | 1 | 4728809202 | |
| 14 | Sealing | 1 | 4728809202 4728809342 4728809372 | |
| 15 | Cover | 1 | 4728809202 | |
| 16 | Fillister-Head Screw M6x25 | 15 | ||
| 17 | O-Ring ISO3601-8x2 | 1 | 4728809202 4728809342 4728809372 4729009272 | 8970700304 |
| 18 | O-Ring ISO3601-18x2 | 5 | 4728809202 4728809342 4728809372 4729009272 4729009292 | 8970815204 |
| 19 | Valve solenoid | 1 | 4728809202 4729009272 | 4423002221 |
| 20 | Sealing | 1 | 4728809202 4728809342 4728809372 4729009272 | |
| 21 | Cover | 1 | 4728809202 | |
| 22 | Screw | 4 | 4728809202 | |
| 23 | Sealing | 1 | 4728809342 4728809372 | |
| 24 | Cover | 1 | ||
| 25 | Valve solenoid | 1 | 4729009292 | |
| 26 | O-Ring ISO3601-15x2 | 1 | 4728809372 4729009292 | 8977702504 |
| 27 | Cover | 1 | ||
| 28 | Screw | 2 | ||
| 29 | Silencer | 1 | 4324070600 | |
| 30 | screw plug | 1 |
