Hydraulic clutch pedal unit unsynchro
Twin-Cyl.Compressor 704cc,flangemounted
Part Number::
9650010580
Gross Unit Price:
0.00
Features and Benefits
-
BrandWABCO
-
Part typePremium original quality
-
Product categoryDevice
-
ApplicationDAF
-
Calculated Volume (dm³)0
-
Electrical connectionTyco C-114-18740-1 Rev "D"
-
Max. operating pressure181.30 psi
-
Port thread 11Voss 232 NG8
-
Port thread 12Voss 232 NG8
-
Port thread 2M14 x 1.5
-
Port thread 21Voss 230 NG8
-
Port thread 22Voss 232 NG8
-
Port thread 3Integrated silencer
-
Stroke3.35 / 5.31 in
-
Technical specificationOE specification
-
Temperature range-35°C to +70°C
-
TypeBrake Pedal and Clutch Pedal
-
Voltage24 V
-
GTIN04057875299189
-
UPC193133449515
-
Weight (kg)0.001
-
Weight (lb)0.0022046
Replaces
-
FREIGHTLINERA02-14020-000
-
KENWORTHS9650010580
-
MACK6300-9650010580
-
MERITORS9650010580
-
PETERBILTS9650010580
-
VOLVOWAB9650010580
Service & Repair
List of Spare Parts
| 1 | Support | 1 | ||
| 2 | Hex socket set screw DIN913-M6x50 | 1 | ||
| 3 | Self locking hexagon nut DIN985-M6 | 1 | 8103170014 | |
| 4 | Arm | 1 | ||
| 5 | Fork | 1 | ||
| 6 | Spring | 1 | ||
| 7 | Fork | 1 | ||
| 8 | Cheese Head Screw | 3 | ||
| 9 | Axle | 1 | ||
| 10 | Pedal | 1 | ||
| 11 | Cheese Head Schrew | 1 | ||
| 12 | Wiring Harness | 1 | ||
| 13 | Seal | 1 | 9650019012 | |
| 14 | Bearing piece | 1 | 9650019012 | |
| 15 | Retaining Ring | 1 | 9650019012 9650019002 | 8952267304 |
| 16 | Body | 1 | 9650019002 | |
| 17 | Body | 1 | ||
| 18 | O-Ring ISO3601-30,8x3,6 | 1 | 9650019002 | |
| 19 | Container | 1 | 9650019012 | |
| 20 | O-Ring ISO3601-40,64x5,33 | 1 | 9650019002 | |
| 21 | Guide Ring | 1 | 9650019002 |
