盘式制动器
Twin-Cyl.Compressor 704cc,flangemounted
材料编号:
40130007
毛单价:
0.00
Features and Benefits
-
品类WABCO
-
产品型号高端原配质量
-
技术标准OE标准
-
产品类别设备
-
刹车盘38 mm
-
反向40 130 008
-
容积计算值（dm³）31.37
-
支架4x M18 x 1.5
-
替换制动器是
-
版本号Without Pads
-
直径410.0 mm
-
结构模型1300V-G
-
行程19.0 mm
-
装配侧右边
-
Size (mm x mm x mm)441 x 319 x 223
-
UPC193133476528
-
全球贸易项目代码04057875153658
-
重量 (kg)28.94
-
重量 (lb)63.8
替代
-
MERCEDES-BENZ4054210498
-
MERCEDES-BENZA4054210498
Doc Type
drawing
Locale
de
Artical Number
6401300070____053_dascheck_e10_page-1---notset
服务&维修
配件列表
| 1 | 制动钳桥架 | 1 | ||
| 2 | Caliper housing | 1 | ||
| 3 | 扩展器单元 | 1 | 6401300002 | |
| 4 | 密封 | 1 | 6401300002 | |
| 5 | 压力元件 | 1 | ||
| 6 | Pressure Spring | 1 | 6401300002 | |
| 7 | Screw | 1 | 6401300002 | |
| 8 | BRAKE SHOE | 2 | ||
| 9 | Safety device | 2 | 13731038 | |
| 10 | Tube clip | 1 | 17853023 | |
| 11 | 磨耗指示器 | 1 | ||
| 12 | Down holder spring | 2 | ||
| 13 | Retaining washer DIN6799-6 | 4 | ||
| 14 | 销针 | 2 | ||
| 15 | 销 | 1 | 6401300002 | |
| 16 | Compression spring DIN2098-0,63x6,3x11 | 1 | 6401300002 | |
| 17 | Hexagon socket pipe plug DIN906-M16x1,5 | 1 | 6401300002 | |
| 18 | 密封 | 2 | ||
| 19 | 衬套 | 3 | 17630017 | |
| 20 | 销 | 1 | ||
| 21 | Head screw | 2 | ||
| 22 | 盖板 | 2 | ||
| 23 | 销 | 1 | ||
| 24 | Bearing bushing 40x45x20-ST/940S-1000 V | 1 | ||
| 25 | Supporting washer SEEGER SS40X50X2/5 | 1 | 6401300002 | |
| 26 | 密封圈 | 1 | 6401300002 | |
| 27 | Radial Shaft Seal | 1 | 6401300002 | |
| 28 | 盖板 | 1 | 6401300002 | |
| 29 | 波形密封圈 | 1 | 6401300002 | |
| 30 | 插头 | 1 | 6401300002 | |
| 31 | Head screw | 4 | ||
| 32 | Spider Plate | 1 |
