ALR relais lucht
Twin-Cyl.Compressor 704cc,flangemounted
Onderdeelnummer::
4757111180
Brutoprijs/Stuk:
1229.00
Kenmerken en voordelen
-
MerkWABCO
-
Type onderdeelPremium OE kwaliteit
-
Technische specificatieOE specificatie
-
ProductcategorieApparaat
-
Aanstuurdruk13 bar
-
Afstand tussen bouten84x84 mm
-
Bereik van aanpassing0.5 to 3.0 bar
-
Berekend volume (dm³)8.357
-
Inlaatdruk10.2 bar
-
Max. bedrijfsdruk13.0 bar
-
OntluchtingWith silencer
-
Operationeel bereik0.5 to 3.0 bar
-
Ophanging4x M8
-
Regelverhouding1:8
-
Rempunt0.6 bar
-
Schroefdraad poort 1M22 x 1.5 JED-388
-
Schroefdraad poort 2M16 x 1.5 JED - 388
-
Schroefdraad poort 4M16 x 1.5 JED - 388
-
Schroefdraad poort 41M16 x 1.5 JED-388
-
Schroefdraad poort 42M16 x 1.5 JED-388
-
Temperatuurbereik-40°C to +80°C
-
Type werkingRelaisklep
-
VoertuigtypePneumatic
-
Afmetingen (MM x MM x MM)289 x 243 x 119
-
GTIN04057875225508
-
Gewicht (kg)1.892
-
UPC193133314820
-
Gewicht (lb)4.1711
vervangt
-
DAF1518973
-
EVOBUSA0034312212
-
MERCEDES-BENZ0034312212
-
MERCEDES-BENZA0034312212
-
PACCAR1518973
-
SCANIA1935094
Doc Type
drawing
Locale
multi
Artical Number
4757111160_-_653_g_01
Service & Reparatie
Lijst van vervangingsonderdelen
| 1 | onderkant komponent | 1 | ||
| 2 | Slotted shouder screw | 1 | ||
| 3 | Demper | 1 | 4324070500 | |
| 4 | Schroef | 2 | 8912120014 | |
| 5 | nok | 1 | 4757110804 | |
| 6 | Spannapparaat | 1 | 8953703704 | |
| 7 | VEER | 1 | 8965123704 | |
| 8 | Pijpleiding | 0 | ||
| 9 | Dichting | 1 | 4757110002 | 4757111404 |
| 10 | Afdekking | 1 | 4757116534 | |
| 11 | Hexagon thin nut DIN439-2-BM12 | 1 | ||
| 12 | banjobout | 1 | 8913008814 | |
| 13 | Beschermkap | 1 | 4757110002 | 8980121594 |
| 14 | CILINDERSCHR. | 2 | 8912116404 | |
| 15 | Zuigerring | 1 | 4757110002 | 8970950204 |
| 16 | Zuiger | 1 | 4757116214 | |
| 17 | O-Ring ISO3601-15x3 | 1 | 4757110002 | 8970811604 |
| 18 | CILINDERSCHR. | 2 | 8912116404 | |
| 19 | Cilinder | 1 | ||
| 20 | COMPRESSION SPRING | 1 | 4757110002 | 8965140104 |
| 21 | O-RING | 4 | 4757110002 | 8970800804 |
| 22 | Glijstuk | 1 | 4757118014 | |
| 23 | RETAINING RING | 1 | 4757110002 | 8105420094 |
| 24 | STOFHOES MIN20 | 1 | 8977539404 | |
| 25 | MOER 50 | 1 | 8915810004 | |
| 26 | Hexagon screw | 1 | 8101260484 | |
| 27 | Hexagon head screw ISO4017-M8x55 | 4 | 8101260714 | |
| 28 | DRUKVEER | 1 | 8965130704 | |
| 29 | Roller | 1 | 4757101304 | |
| 30 | klepstoter | 1 | 4757107704 | |
| 31 | O-ring ISO3601-4,3x2,4 | 1 | 4757110002 | 8970803004 |
| 32 | O-RING | 1 | 4757110002 | 8970805304 |
| 33 | Klep | 1 | 4757110002 | 8995058422 |
| 34 | O-Ring ISO3601-49,50x3 | 1 | 4757110002 | 8977726264 |
| 35 | Klepzittingring | 1 | 4757101434 | |
| 36 | Retaining ring DIN472-JV55x2 | 1 | ||
| 37 | nutring | 1 | 4757110002 | |
| 38 | Zuiger | 1 | 4757106284 | |
| 39 | Retaining ring DIN471-A17x1 | 1 | 4757110002 | |
| 40 | Afstandsring | 1 | ||
| 41 | MEMBRAAN | 1 | 4757110002 | |
| 42 | inzetring | 1 | ||
| 43 | Zuiger | 1 | ||
| 44 | O-Ring min20 | 1 | 4757110002 | 8970803704 |
| 45 | Klep | 2 | 4757110002 | 8995058304 |
| 46 | Kap | 1 | ||
| 47 | Cylindrical compression spring | 1 | ||
| 48 | Kap | 1 | 4757110002 | 4757100424 |
| 49 | SNAP RING | 1 | 4757110002 | 8105180124 |
| 50 | Retaining ring DIN472-17x1 | 1 | 4757110002 | |
| 51 | Kap | 1 | ||
| 52 | Cylindrical compression spring | 1 | 4757110002 | |
| 53 | Carrosserie | 1 | 4757100154 | |
| 54 | Zuiger | 1 | ||
| 55 | O-Ring min20 | 2 | 4757110002 | 8970803704 |
| 56 | Cylindrical compression spring | 1 | ||
| 57 | Zuiger | 1 | 4757106274 | |
| 58 | Retaining ring DIN472-33x1,2 | 1 | ||
| 59 | KAP MIN50 | 1 | 8980113504 |
