盘式制动器
Twin-Cyl.Compressor 704cc,flangemounted
材料编号:
40175064
毛单价:
0.00
Features and Benefits
-
品类WABCO
-
产品型号高端原配质量
-
技术标准OE标准
-
产品类别设备
-
刹车盘34 mm
-
容积计算值（dm³）18.4826
-
支架6x M14 x 1.5
-
替换制动器是
-
版本号Without Pads
-
电气连接插座
-
直径330.0 mm
-
结构模型PAN 17
-
行程21.0 mm
-
装配侧左
-
Size (mm x mm x mm)357 x 301 x 172
-
UPC193133226789
-
全球贸易项目代码04057875153825
-
重量 (kg)20.527
-
重量 (lb)45.2542
替代
-
DAF1522111R
-
PACCAR1522111
-
RENAULT5001852882
Doc Type
drawing
Locale
de
Artical Number
6401750640____053_dascheck_m20_page-1---notset
Doc Type
brochure
Locale
nl
Artical Number
wabco_reman_solutions_core_return_guidelines
Doc Type
brochure
Locale
en
Artical Number
zf_reman_core_return_guidelines
Doc Type
catalog
Locale
hr
Artical Number
wabco_reman_solutions_catalogue_2021_web
Doc Type
market_information
Locale
en
Artical Number
19060
服务&维修
配件列表
| 1 | 制动钳 | 1 | ||
| 2 | Pressure Spring | 2 | 6401759462 | |
| 3 | 合膜单元 | 1 | 6401759462 | |
| 4 | 杠杆，手柄 | 1 | 6401759462 | |
| 5 | 密封 | 0 | 6401759462 | |
| 6 | 盖板 | 1 | ||
| 7 | Screw | 8 | 6401759462 | 13730203 |
| 8 | 密封 | 1 | 13227166 | |
| 9 | 插头 | 1 | 6401759462 | |
| 10 | Bolt,special Foundation Brake | 1 | ||
| 11 | 密封 | 2 | 13227143 | |
| 12 | Cheese Head Screw, full thread | 2 | ||
| 13 | 盖板 | 2 | ||
| 14 | Bolt,special Foundation Brake | 1 | ||
| 15 | Down holder bracket | 1 | 13166025 | |
| 16 | Hexagon Bolt | 1 | 18429154 | |
| 17 | Boot | 1 | 6401759462 | |
| 18 | 压力元件 | 1 | 6401759402 | |
| 19 | Safety device | 1 | ||
| 20 | Safety device | 1 | 13731038 | |
| 21 | Safety device | 2 | ||
| 22 | Spider Plate | 1 | 6401750012 |
