Twin-Cyl.Compressor 704cc,flangemounted
Part Number::
4324330480
Gross Unit Price:
0.00
Features and Benefits
-
BrandWabco Original
-
Part typePremium original quality
-
Product categoryDevice
-
Calculated Volume (dm³)31.451
-
Cartridge typeCoalescing Cartridge
-
ExhaustJED-463-0
-
Max. operating pressure188.5 psi
-
Opening pressure159.54 psi
-
Port thread 111/2" - 14 NTPF
-
Port thread 211/2" - 14 NPTF
-
Port thread 3JED-463-0
-
Port thread 4/231/4" - 18 NPTF
-
Technical specificationOE specification
-
Temperature range-40°C to +65°C
-
Voltage12 V
-
GTIN04057875925217
-
Size (mm x mm x mm)387 x 387 x 210
-
UPC193133437697
-
Weight (kg)9.5572026
-
Weight (lb)21.07
Replaces
-
FREIGHTLINERTDAS4324330480
-
KENWORTHS432-433-048-0
-
MACK8235-S4324330480
-
MACK6300-4324330480
-
MERITORS4324330480
-
PETERBILTS432-433-048-0
-
VOLVOTDAS4324330480
-
VOLVOWAB4324330480
Doc Type
maintenance_instruction
Locale
en
Artical Number
mm34
Doc Type
maintenance_instruction
Locale
en
Artical Number
tp19005
Service & Repair
List of Spare Parts
| 1 | Body | 1 | ||
| 2 | O-Ring ISO3601-14x3 | 1 | 8970815614 | |
| 3 | O-Ring ISO3601-48,9x2,62 | 1 | ||
| 4 | Valve head | 1 | 4324312504 | |
| 5 | Valve | 1 | ||
| 6 | Piston | 1 | ||
| 7 | Washer | 2 | 8951052734 | |
| 8 | Cylindrical Compression Spring | 1 | 8965166134 | |
| 9 | Washer | 1 | 8951090604 | |
| 10 | O-Ring ISO3601-47x2 | 1 | ||
| 11 | Bottom | 1 | 4324315512 | |
| 12 | Retaining ring DIN472-JV55x2 | 1 | ||
| 13 | Thread Fitting | 2 | ||
| 14 | O-Ring ISO3601-33x5 | 2 | ||
| 15 | Desiccant and Oil Separator Cartridge | 2 | 4329012252 | |
| 16 | Valve | 2 | ||
| 17 | O-Ring ISO3601-30x3 | 2 | 8977703404 | |
| 18 | Bushing | 2 | ||
| 19 | Compression Spring, special | 2 | ||
| 20 | Piston | 2 | 4324056204 | |
| 21 | Diaphragm | 2 | 8971216004 | |
| 22 | O-Ring ISO3601-3,3x3 | 2 | 8977718004 | |
| 23 | Cover | 1 | ||
| 24 | 3/2 Valve Solenoid | 1 | ||
| 25 | Cheese head screw DIN6912-M6x35 | 8 | ||
| 26 | Cover | 1 | ||
| 27 | Washer DIN125-1-6,4x12,5x1,6 | 4 | 8104010094 | |
| 28 | O-Ring ISO3601-9x2,5 | 3 | ||
| 29 | Valve body | 2 | ||
| 30 | Compression Spring | 1 | ||
| 31 | O-Ring ISO3601-16,3x2,4 | 1 | ||
| 32 | O-Ring ISO3601-23x2 | 1 | 8970827904 | |
| 33 | Valve Seat | 1 | ||
| 34 | O-Ring ISO3601-36x2,5 | 1 | 4324139232 | 8977829104 |
| 35 | Heater 12V | 1 | 4324139232 | |
| 36 | Kit: Switch | 1 | 4324139232 | 8940409402 |
| 37 | Support | 1 | 4324139232 | 4324083504 |
| 38 | Tapping screw ISO7049-B2,9x6,5 | 1 | 4324139232 | |
| 39 | Male Connection | 1 | 4324139232 | |
| 40 | Screw | 2 | 4324139232 | |
| 41 | Valve body | 1 | ||
| 42 | Conical Compression Spring | 1 | ||
| 43 | Washer | 1 | ||
| 44 | Retaining ring DIN472-17x1 | 1 | ||
| 45 | O-Ring ISO3601-19,3x2,4 | 1 | 4324709212 | |
| 46 | O-Ring ISO3601-16x2 | 1 | ||
| 47 | Cover | 1 | ||
| 48 | O-Ring ISO3601-28x2,5 | 1 | 4324709212 | |
| 49 | Piston | 1 | 4324709212 | |
| 50 | O-Ring ISO3601-29,1x2,55 | 1 | 4324709212 | |
| 51 | Insert | 1 | 4324709212 | |
| 52 | Cover | 1 | 4324709212 | |
| 53 | Retaining ring DIN472-36x1,5 | 1 | 4324709212 | |
| 54 | Washer DIN1441-16,4x28x2 | 1 | ||
| 55 | Cheese Head Screw ISO4762-M16x1,5 | 1 |
