1 | Carrocería | 1 | ||
2 | O-Ring ISO3601-21,3x2,4 | 2 | 4801029352 | 8977728174 |
3 | Guía | 2 | 4801029352 | |
4 | Resorte | 2 | 4801029352 | 8965168154 |
5 | Cuerpo de válvula | 2 | 4801029352 | |
6 | O-Ring ISO3601-37,77x2,62 | 2 | 4801029352 | 8977862704 |
7 | Anillo de asiento de válvula | 2 | 4801029352 | |
8 | Retaining ring DIN472-42x1,75 | 2 | 4801029352 | |
9 | Junta | 2 | 4801029352 | |
10 | Pistón | 2 | 4801029352 | |
11 | Anel O | 2 | 4801029352 | 8970800404 |
12 | Sealing | 1 | 4801029352 | |
13 | Carrocería | 1 | ||
14 | Cheese head screw ISO14580-M8x25 | 8 | 4801029352 | |
15 | Sealing | 1 | ||
16 | Unidad Electrónica Independiente (ECU) | 1 | ||
17 | Soporte | 1 | ||
18 | Sealing | 1 | 4801029352 | |
19 | 1 | |||
20 | Tapón protección | 5 | 8980204622 | |
21 | Tapón protección GIO TEBS E | 1 | 8980204632 | |
22 | Stud NULL-M12x1,5 | 2 | ||
23 | Schraube | 6 | 4801029352 | |
24 | Filtro | 2 | 4802049212 | 4801022202 |
25 | O-Ring ISO3601-24x2 | 1 | 8970866804 | |
26 | Racores rápidos | 6 | 4801029332 | 8938000022 |
27 | Filtro | 1 | ||
28 | Recto M16-8/6 ABC | 2 | 4801029332 | 8938000012 |
29 | Racores rápidos | 1 | 4801029332 | 8938000042 |
30 | Silenciador | 2 | 4324070272 | |
31 | Anillo "O" | 1 | 8970815204 | |
32 | PEM | 1 | 4615130200 | |
33 | Tornillo, cab.cilíndrica ISO4762-M6x50 | 3 | 8101203064 | |
34 | Clip de seguridad | 3 | 4801029312 | |
35 | Clip de seguridad | 10 | 4801029312 |
