1 | Bloque motor | 1 | ||
2 | Upper Part of the Connect | 1 | ||
3 | Bushing | 1 | 9111559262 | |
4 | Pistón | 1 | 9111559262 | |
5 | Retaining ring DIN472-19x1 | 2 | 9111559262 | |
6 | Wrist Pin | 1 | 9111559262 | |
7 | Segmento | 1 | 9111559262 | |
8 | Oil Control Ring ISO6621-85x2 | 2 | 9111559262 | 8956704144 |
9 | Junta | 1 | 9111559202 9121400492 9111559212 | |
10 | Suction leaf | 1 | 9111559202 9121400492 9111559212 | |
11 | Cabeza | 1 | 9121400492 9111559212 | 9111530504 |
12 | Culata | 1 | 9121400492 | |
13 | Muelle de compres. Cilínd. | 1 | 9121400492 | |
14 | Pistón | 1 | 9121400492 | 9120006204 |
15 | Junta tórica | 2 | 9121400492 | |
16 | Tope | 1 | 9121400492 | |
17 | Casquillo tensor | 2 | 9121400492 | |
18 | Tornillo | 2 | ||
19 | Pasador | 1 | 9121400492 | 8920135644 |
20 | Válvula de presión | 1 | 9111559202 9121400492 9111559212 | 4111515002 |
21 | Hexagon nut ISO4161-M5 | 1 | 9111559202 9121400492 9111559212 | |
22 | Hexagon flange bolt DIN6921-M5x13 | 2 | 9121400492 | |
23 | Plato | 1 | 9121400492 | 9111531004 |
24 | Junta | 1 | 9111559202 9121400492 9111559212 | |
25 | Cubierta | 1 | 9121400492 | 9111556554 |
26 | Ball ISO3290-10 | 1 | 9121400492 | 8107010134 |
27 | Resorte de compresión | 1 | 9111559202 9121400492 | |
28 | Tapón roscado DIN908-M12x1,5 | 1 | 9121400492 | 8109020104 |
29 | Kit: Junta de estanqueidad | 1 | 9121400492 | 9121799252 |
29 | Tornillo, cabeza hexag., flange | 4 | 9121400492 | 8912119994 |
30 | Tornillo, cab.cilíndrica ISO14580-M6x60 | 1 | 9121400492 | |
30 | Kit: Junta de estanqueidad | 1 | 9121400492 | 9121799252 |
31 | Tuerca de rueda | 1 | 9121709212 | 8103410034 |
32 | Rueda dentada | 1 | ||
33 | Manguito | 1 | 9121400392 | 9111552004 |
34 | Cigüeñal | 1 | 9121400392 | |
35 | Anillo "O" | 1 | 9111559202 9121400392 9121709212 9111559212 | 8970731534 |
36 | Brida | 1 | 9121400392 | 9111536074 |
37 | Tornillo | 2 | 9121400392 9121709212 | 8101390014 |
38 | Connecting Rod, lower part | 1 | ||
39 | Tornillo, cab.cilíndrica ISO14580-M6x35 | 2 | 9111559262 9121400392 | 8912019294 |
40 | Tapa | 1 | 9111559262 9121400392 9111559212 | 8950735894 |
41 | Anillo de Sello | 1 | 8114010274 | |
42 | Hexagon socket pipe plug DIN908-M10x1 | 1 |
