1 | Carrocería | 1 | ||
2 | Pistón | 1 | 9730096314  | |
3 | O-Ring ISO3601-30,3x2,4 | 1 | 9730090002  | |
4 | Anillo de Retencion | 1 | 8105180254  | |
5 | Anillo "O" | 5 | 9730090002  | 8970865104  |
6 | Pistón | 1 | 9730096224  | |
7 | O-Ring ISO3601-21,89x2,62 | 1 | 9730090002  | 8977864504  |
8 | Arandela | 1 | ||
9 | Tuerca | 1 | 8915028444  | |
10 | Silenciador | 1 | 9730092212  | |
11 | Tornillo | 4 | ||
12 | Pistón | 1 | 9730096324  | |
13 | Resorte | 1 | 8960363604  | |
14 | Asiento del Resorte | 1 | 8950732114  | |
15 | Anillo "O" | 1 | 9730090002  | 8970700704  |
16 | Válvula | 1 | 9730090002  | 8995068462  |
17 | Anillo "O" | 2 | 9730090002  | 8970862704  |
18 | Anillo de asiento de válvula | 1 | 9730091404  | |
19 | Anillo de Retencion | 2 | ||
20 | Conical compression spring | 1 | ||
21 | Pistón | 1 | 9730096272  | |
22 | Anillo "O" | 1 | 9730090002  | 8970865504  |
23 | O-Ring ISO3601-7,1x1,6 | 1 | 9730090002  | |
24 | Tornillo | 1 | 9730023004  | |
25 | Resorte | 1 | 8965162724  | |
26 | Anillo de cierre | 1 | 9730090002  | |
27 | Pistón | 1 | 9730026314  | |
28 | Kit: Válvula | 1 | 9730090002  | 8995060012  |
29 | Cylindrical compression spring | 1 | 9730090002  | |
30 | Tapa | 1 | 9730090002  | |
31 | Cubierta | 1 | 9730096504  | |
32 | Anillo "O" | 1 | 9730090002  | 8970865404  |
33 | Pistón | 1 | ||
34 | Anillo "O" | 1 | 9730090002  | 8977863304  |
35 | Cubierta | 1 | ||
36 | Hexagon head screw ISO4017-M8x70 | 4 | ||
37 | Tuerca | 4 | 8103040174  | |
38 | JUNTA ESTANQUEIDAD DIN7603-A16x20 | 2 | 8114010574  | |
39 | Tapón roscado | 2 | 8930117114  |
