Compressor (Single Cylinder)
Twin-Cyl.Compressor 704cc,flangemounted
Material Number:
4111416407
Gross Unit Price:
0.00
Features and Benefits
-
BrandWABCO Original
-
Part typePremium original quality
-
Calculated Volume (dm³)6.062
-
CoolingAir
-
LubricationLubrication supplied from engine
-
Max. operating pressure18.0 bar
-
Operating speed3000 (1/min)
-
Piston diameter75.0 mm
-
Piston stroke36 mm
-
Port thread 0M26 x 1.5
-
Port thread 2M26 x 1.5
-
Port thread 8.1M10 x 1
-
Port thread 8.2M22 x 1.5
-
Product categoryDevice
-
Swept volume (cm3)159 cm3
-
Technical specificationOE specification
-
TypeSingle Cylinder
-
GTIN04057875155393
-
Size (mm x mm x mm)185 x 129 x 254
-
UPC193133478270
-
Weight (kg)9.7
-
Weight (lb)21.38
Replaces
-
DAF1518581R
-
EVOBUSA00313150010080
-
MERCEDES-BENZ003131500180
-
MERCEDES-BENZ0031315001
-
MERCEDES-BENZA00313150010080
-
MERCEDES-BENZ00313150010080
Doc Type
brochure
Locale
en
Artical Number
wabco_reman_solutions_core_return_guidelines
Doc Type
repair_test_instructions
Locale
en
Artical Number
91200095
Service & Repair
List of Spare Parts
| 1 | Crankcase | 1 | ||
| 2 | Crankshaft | 1 | 4111416904 | |
| 3 | O-Ring ISO3601-57x3 | 1 | 8976709004 | |
| 4 | Cover | 1 | 4111416604 | |
| 5 | Hexagon head screw ISO4017-M8x20 | 4 | ||
| 6 | O-Ring ISO3601-88x3 | 1 | 4111400022 4111419232 | 8976701904 |
| 7 | Bearing Cover | 1 | 4111400022 4111419232 | |
| 8 | Countersunk head screw ISO7046-M8x16 | 4 | 4111400022 4111419232 | |
| 9 | Rotary Shaft Seal DIN3760-A28x40x7 | 1 | 4111400022 4111419232 | 8114080404 |
| 10 | Washer DIN125-1-19x34x3 | 1 | ||
| 11 | Hexagon thin nut DIN439-2-BM18x1,5 | 1 | ||
| 12 | Sealing Push in Cap DIN443-A16 | 2 | 4111419272 | 8104070034 |
| 13 | Sealing | 1 | 4111400022 4111419282 | 8973169952 |
| 14 | Cheese Head Screw ISO14580-M6x35 | 2 | 4111419272 | 8912019294 |
| 15 | Connecting Rod | 1 | 4111419272 | 4111417322 |
| 16 | Piston | 1 | 4111419272 | 4111416232 |
| 17 | Bearing | 1 | 4111400022 4111419232 | 4115223404 |
| 18 | Needle Roller DIN5402-B3x9,8G5 | 2 | 4111419282 | 8107020234 |
| 19 | Suction reed valve | 1 | 4111419282 | 4110410514 |
| 20 | Valve Seat | 1 | 4111419282 | |
| 21 | Washer | 1 | 4111419282 | |
| 22 | Pressure reed valve | 1 | 4111419282 | 4110410504 |
| 23 | Pressure valve stop | 1 | 4111419282 | 4110414904 |
| 24 | Bush | 2 | 4111419282 | 8997574014 |
| 25 | Setscrew | 2 | 4111419282 | |
| 26 | Sealing | 1 | 4111400022 4111419282 | 8973169964 |
| 27 | Cylinder cover | 1 | 4111419282 | 4111416514 |
| 28 | Hexagon Flange Bolt | 4 | 4111419282 | 8912017014 |
| 29 | Sealing Ring DIN7603-26x32 | 1 | 4111400022 | 8114011004 |
| 30 | Sealing Ring DIN7603-A10x14 | 1 | 4111400022 | 8114011724 |
