Brake Actuator
Vehicle application (India): TATA
Twin-Cyl.Compressor 704cc,flangemounted
Material Number:
100252690
Gross Unit Price:
0.00
Vehicle application (India): TATA
Features and Benefits
-
BrandWABCO
-
Part typePremium original quality
-
Bolt lengths40.0 mm
-
Bolt threadsM16 x 1.5
-
Calculated Volume (dm³)0
-
Clevis pins12.5 mm
-
Distance between bolts120.6 mm
-
Max. operating pressure10.0 bar
-
Output force11500 N
-
Port thread 11M18 x 1.5
-
Product categoryDevice
-
Push-rod length72 mm
-
Push-rod threadM14 x 1.50
-
Release pressure4.7 bar
-
Return-spring force145 N
-
Stroke57.0 mm
-
Technical specificationOE specification
-
Temperature range-40°C to +80°C
-
Total length202.0 mm
-
Type20/75
-
Type of operationCam
-
VersionWith boot
-
YokeWith
-
GTIN04057875002628
-
UPC193133048282
-
Weight (kg)0.001
-
Weight (lb)0.0022046
Doc Type
drawing
Locale
en
Artical Number
100252080____053_dascheck_g3_page-1---notset
Service & Repair
List of Spare Parts
| 1 | Cylinder assembly | 1 | ||
| 2 | Rod | 1 | 9254917392 | |
| 3 | Bearing | 1 | ||
| 4 | Sealing | 1 | ||
| 5 | Spring | 1 | ||
| 6 | Ram assembly | 1 | ||
| 7 | O-Ring, dynamical | 1 | ||
| 8 | Bearing | 1 | ||
| 9 | O-Ring, statical | 1 | ||
| 10 | Flange (Anodising) | 1 | 100275562 | |
| 11 | Spring Retainer | 1 | ||
| 12 | Retaining Ring | 1 | 8952266974 | |
| 13 | Pressure screw | 1 | 8932204272 | |
| 14 | O-Ring, statical | 1 | ||
| 15 | O-Ring, statical | 1 | ||
| 16 | O-Ring, statical | 1 | 8979802304 | |
| 17 | Washer, special type | 1 | 8951800024 | |
| 18 | Adapter, inside/outside thread | 1 | ||
| 19 | Hexagon Head Screw, full thread | 8 | 8912000264 | |
| 20 | O-Ring, dynamical | 1 | ||
| 21 | Stem plug | 1 | ||
| 22 | Diaphragm | 1 | M870580 | |
| 23 | Pushrod assembly | 1 | ||
| 24 | Conical Spring | 1 | ||
| 25 | Dust shield | 1 | ||
| 26 | Locking nut | 1 | 8919900074 | |
| 27 | Boot | 1 | ||
| 28 | Non pressure plate assembly | 1 | ||
| 29 | Hose nipple | 2 | ||
| 30 | Pipe | 1 | ||
| 31 | Spring Washer DIN6888-16.5x27.4x3.5 | 2 | ||
| 32 | Hexagon nut | 2 | ||
| 33 | Fork | 1 | 9254914202 | |
| 34 | Pin | 1 | 8920100084 | |
| 35 | Splint | 1 | 8105110274 | |
| 36 | Clamping Unit | 1 | ||
| 37 | Screw, special type | 1 | ||
| 38 | Nut, special type | 1 | ||
| 39 | Locking nut | 8 | ||
| 40 | Washer, sealing type | 1 | ||
| 41 | Nut, special type | 1 | 8919900104 | |
| 42 | PIN | 1 | ||
| 43 | Closing Valve | 0 |
