1 | Body | 1 | ||
2 | O-Ring ISO3601-33x5 | 2 | ||
3 | Air Dryer Cartridge, compressed-air system | 2 | 4324100202  | |
4 | Screw | 2 | ||
5 | Heater | 1 | 8942600742  | |
6 | Tapping screw ISO7049-B2,9x6,5 | 1 | ||
7 | Support | 1 | 4324083504  | |
8 | O-Ring ISO3601-36x2,5 | 1 | 8977829104  | |
9 | Retaining Ring DIN472-20x1 | 1 | 8105180124  | |
10 | Washer | 1 | ||
11 | Conical Compression Spring | 1 | ||
12 | Valve body | 1 | ||
13 | O-Ring ISO3601-9x2,5 | 3 | 4324339242  | |
14 | Tyre inflation port | 1 | 9324009202  | |
15 | Compression Spring | 1 | 4324339242  | |
16 | Valve body | 2 | 4324339242  | |
17 | O-Ring ISO3601-16,3x2,4 | 1 | 4324339242  | |
18 | O-Ring ISO3601-23x2 | 1 | 4324339242  | 8970827904  |
19 | Valve seat | 1 | 4324339242  | |
20 | Valve | 2 | 4324339212  | |
21 | O-Ring ISO3601-30x3 | 2 | 4324339212  | 8977703404  |
22 | Bush | 2 | ||
23 | Compression Spring, special | 2 | 4324339212  | |
24 | Piston | 2 | 4324339212  | 4324056204  |
25 | Diaphragm | 2 | 4324339212  | 8971216004  |
26 | O-Ring ISO3601-3,3x3 | 2 | 4324339212  | 8977718004  |
27 | Cover | 1 | ||
28 | Cover | 1 | ||
29 | Cheese head screw DIN6912-M6x35 | 8 | ||
30 | Washer DIN125-1-6,4x12,5x1,6 | 4 | 8104010094  | |
31 | 3/2 Solenoid Valve | 1 | ||
32 | O-Ring ISO3601-14x3 | 1 | 8970815614  | |
33 | O-Ring ISO3601-48,9x2,62 | 1 | ||
34 | Valve head | 1 | 4324312504  | |
35 | Valve | 1 | ||
36 | Piston | 1 | ||
37 | Washer | 3 | 8951052734  | |
38 | Washer | 4 | 8951052764  | |
39 | Cylindrical Compression Spring | 1 | 8965166134  | |
40 | O-Ring ISO3601-47x2 | 1 | ||
41 | Washer | 1 | 8951090604  | |
42 | Bottom | 1 | 4324315512  | |
43 | Retaining ring DIN472-JV55x2 | 1 |
