Twin-Cyl.Compressor 704cc,flangemounted
Material Number:
9700514990
Gross Unit Price:
0.00
Features and Benefits
-
BrandWABCO
-
Part typePremium original quality
-
Calculated Volume (dm³)0
-
Distance between holes110 mm
-
Important informationPlease follow the installation instructions of the vehicle manufacturer
-
Length397 mm
-
Max. operating pressure10.0 bar
-
MediumBrake fluid SAE J 1703
-
Mounting4x Ø 9.0 mm
-
Port thread 1-4M14 x 1.5
-
Port thread 11M16 x 1.5 JED - 464
-
Port thread 12M12 x 1.5 JED - 464
-
Port thread 22M12 x 1.5 JED - 464
-
Port thread 31Flap Exhaust
-
Port thread 32Ø 8.0 mm
-
Product categoryDevice
-
Stroke85.0 mm
-
Technical specificationOE specification
-
Temperature range-40°C to +80°C
-
YokeØ 9.42 mm
-
GTIN04057875300571
-
Weight (kg)0.001
-
Weight (lb)0.0022046
Doc Type
drawing
Locale
en
Artical Number
9700514990____005_dascheck_f4_page-1---notset
Service & Repair
List of Spare Parts
| 1 | Hydraulic Body | 1 | ||
| 2 | Splint | 1 | 8105110274 | |
| 3 | Clevis Pin | 1 | ||
| 4 | Yoke | 1 | 8958000152 | |
| 5 | Plate | 1 | ||
| 6 | Bellows | 1 | 9709054524 | |
| 7 | Gasket, special type | 1 | ||
| 8 | Retaining Ring | 1 | ||
| 9 | Piston | 1 | ||
| 10 | Ring, special type | 1 | ||
| 11 | Lip Seal | 1 | ||
| 12 | Cylindrical Compression Spring | 1 | ||
| 13 | Fork | 1 | ||
| 14 | Hexagon head screw DIN6902-M6x20 | 8 | ||
| 15 | Body Pneumatic | 1 | ||
| 16 | O-Ring ISO3601-59x2,5 | 1 | ||
| 17 | Lip Seal | 1 | ||
| 18 | Guide | 1 | ||
| 19 | O-Ring ISO3601-33,3x2,4 | 1 | ||
| 20 | U-Ring | 1 | ||
| 21 | O-Ring ISO3601-8x2,4 | 1 | ||
| 22 | Guide ring | 1 | ||
| 23 | Lip seal ring | 1 | 9700519602 | |
| 24 | Pipe | 1 | ||
| 25 | Valve | 1 | 9700519782 9700519872 | |
| 26 | Mecanic Susp., LSV Relay Emergency | 1 | 9700519782 9700519872 | |
| 27 | Exhaust | 1 | ||
| 28 | Cylindrical compression spring | 1 | ||
| 29 | Cylindrical compression spring | 1 | ||
| 30 | Lip seal ring | 1 | 9700519782 9700519872 | |
| 31 | Valve | 1 | 9700519872 9700519782 | |
| 32 | Cartridge | 1 | 9700515994 | |
| 33 | Lip seal ring | 1 | 9700519872 9700519782 | |
| 34 | Lip seal ring | 1 | 9700519872 9700519782 | |
| 35 | Piston | 1 | 9700519872 9700519782 | 9709036204 |
| 36 | O-Ring ISO3601-18x2 | 1 | 9700519872 9700519782 | 8970815204 |
| 37 | Plug | 1 | 9700519872 9700519782 | 9709010414 |
| 38 | Lip seal ring | 1 | 9700519872 9700519782 | |
| 39 | Spring lock washer | 1 | 9700519872 9700519782 | |
| 40 | Fillister head screw | 2 | 9700519602 | |
| 41 | Hose Connector | 2 | ||
| 42 | Ceramic valve | 1 | 9700519602 | |
| 43 | Protection plug | 1 | ||
| 44 | Bleeder Screw | 1 | 8913505204 | |
| 45 | Strainer | 1 | 8993602604 |
