Trailer Control Valve
Twin-Cyl.Compressor 704cc,flangemounted
Material Number:
9730090010
Gross Unit Price:
571.00
Features and Benefits
-
BrandWABCO
-
Part typePremium original quality
-
Calculated Volume (dm³)3.8631
-
Distance between bolts85x85 mm
-
ExhaustSnap on contour
-
Max. operating pressure8.5 bar
-
Mounting4x M8
-
Multi nominal diameter (from port 1 to x)9 mm
-
Port thread 11M22 x 1.5 JED - 388
-
Port thread 12M22 x 1.5 JED - 388
-
Port thread 22M22 x 1.5 JED - 388
-
Port thread 41M22 x 1.5 JED-388
-
Port thread 42M22 x 1.5 JED-388
-
Port thread 43M16 x 1.5 JED-388
-
Predominance0.20 bar
-
Product categoryDevice
-
Technical specificationOE specification
-
Temperature range-40°C to +80°C
-
GTIN7895851023543
-
Size (mm x mm x mm)193 x 144 x 139
-
UPC193133377337
-
Weight (kg)2.098
-
Weight (lb)4.6253
Replaces
-
ASHOK LEYLAND445332050
-
DAF1506483
-
EVOBUSA0034318205
-
FAW352201552A
-
FAW3522015-52A
-
KOMATSU55116140
-
KÖGEL332607
-
MAN81523016183
-
MAN81523016184
-
MAN81523016186
-
MAN0034318205
-
MERCEDES-BENZ0034311305
-
MERCEDES-BENZ0034311405
-
MERCEDES-BENZ0034313405
-
MERCEDES-BENZ0034313505
-
MERCEDES-BENZ0034318205
-
MERCEDES-BENZA0034318205
-
MERCEDES-BENZ81523016183
-
NEOPLAN81523016184
-
RENAULT5010376021
-
SINOTRUK (CNHTC)WG9000360525/1
-
SINOTRUK (CNHTC)WG9000360525/2
-
TEREX55116140
Service & Repair
List of Spare Parts
| 1 | Body | 1 | ||
| 2 | Cap | 1 | ||
| 3 | O-Ring ISO3601-20,2x3,53 | 1 | 9730090002 8845037182 | 8970862304 |
| 4 | Piston | 1 | 9730096304 | |
| 5 | Cylindrical compression spring | 1 | 8965167984 | |
| 6 | O-Ring ISO3601-24,99x3,53 | 1 | 9730090002 8845037182 | 8977726474 |
| 7 | Piston | 1 | 9730096314 | |
| 8 | O-Ring ISO3601-30,3x2,4 | 1 | 9730090002 8845037182 | |
| 9 | Retaining ring DIN472-37x1,5 | 1 | 8105180254 | |
| 10 | O-Ring ISO3601-56,75x3,53 | 5 | 9730090002 8845037182 | 8970865104 |
| 11 | Piston | 1 | 9730096224 | |
| 12 | O-Ring ISO3601-21,89x2,62 | 1 | 9730090002 8845037182 | 8977864504 |
| 13 | Washer | 1 | ||
| 14 | Hexagon thin nut DIN439-1-M18x1,5 | 1 | 8915028444 | |
| 15 | Venting Guide | 1 | 9730092202 | |
| 16 | Fillister head screw ISO7045-M6x12 | 4 | ||
| 17 | O-Ring ISO3601-24x2,5 | 1 | 9730090002 8845037182 | 8970828404 |
| 18 | Piston | 1 | 9730096324 | |
| 19 | Cylindrical Compression Spring | 1 | 8960363604 | |
| 20 | Spring seat | 1 | 8950732114 | |
| 21 | O-Ring ISO3601-12x2 | 1 | 9730090002 8845037182 | 8970700704 |
| 22 | Valve | 1 | 9730090002 8845037182 | 8995068462 |
| 23 | O-Ring ISO3601-37,77x2,62 | 2 | 9730090002 8845037182 | 8977862704 |
| 24 | Valve seat | 1 | 9730091404 | |
| 25 | Retaining ring 46x1,75 | 2 | ||
| 26 | Conical compression spring | 1 | ||
| 27 | Piston | 1 | 9730096272 | |
| 28 | O-Ring ISO3601-82,15x3,53 | 1 | 9730090002 8845037182 | 8970865504 |
| 29 | O-Ring ISO3601-7,1x1,6 | 1 | 9730090002 8845037182 | |
| 30 | Set Screw S | 1 | 8845037182 | 9730023004 |
| 31 | Cylindrical compression spring | 1 | 8965162724 | |
| 32 | Sealing ring | 1 | 9730090002 8845037182 | |
| 33 | Piston | 1 | 9730026314 | |
| 34 | Kit: Valve | 1 | 9730090002 8845037182 | 8995060012 |
| 35 | Cylindrical compression spring | 1 | 9730090002 8845037182 | |
| 36 | Cap | 1 | 9730090002 8845037182 | |
| 37 | Cover | 1 | 9730096504 | |
| 38 | O-Ring ISO3601-94,85x3,53 | 1 | 9730090002 8845037182 | 8970865404 |
| 39 | Piston | 1 | ||
| 40 | O-Ring ISO3601-101,27x2,62 | 1 | 9730090002 8845037182 | 8977863304 |
| 41 | Guide piece | 1 | 9730091514 | |
| 42 | O-Ring ISO3601-10,1x1 | 1 | 9730090002 8845037182 | |
| 43 | Cylindrical compression spring | 1 | 8965167974 | |
| 44 | Piston | 1 | 9730096294 | |
| 45 | O-Ring ISO3601-11,3x2,4 | 1 | 9730090002 8845037182 | 8970800904 |
| 46 | Cover | 1 | ||
| 47 | Hexagon head screw ISO4017-M8x70 | 4 | ||
| 48 | Hexagon nut DIN934-M8 | 4 | 8103040174 |
